The 80 type Roots blower is a commonly used gas conveying equipment, and the following is a detailed introduction to it:
1、 Basic concepts
The 80 type Roots blower refers to a Roots blower with a model specification of 80. Roots blower is a positive displacement fan that compresses and delivers gas through the relative rotation of two impellers.
2、 Main features
1. High air volume: The 80 type Roots blower has a large air volume range, which can meet the needs of different application scenarios.
2. High pressure: capable of generating high pressure, suitable for situations that require gas pressurization or transportation.
3. Low noise: Advanced noise reduction technology and materials are used to reduce the noise during equipment operation.
4. Good stability: Compact structure and reasonable design ensure stable and reliable operation of the equipment.
3、 Technical parameters
The main technical parameters of the 80 type Roots blower include air volume, pressure, power, etc. Here are some possible technical parameter ranges:
1. Airflow: Usually between 2.36-5.71m3/min, the specific airflow may vary depending on the model and application scenario.
2. Pressure: The adaptable pressure range is wide, covering from 9.8kpa to higher pressure levels (such as 98kpa).
3. Power: Common power levels include 1.5kw, 2.2kw, 3kw, 4kw, 5.5kw, 7.5kw, etc. Among them, 7.5kw is one of the more commonly used power levels.
4、 Application scenarios
The 80 type Roots blower is widely used in multiple fields due to its characteristics:
1. Wastewater treatment: used for wastewater aeration to increase the oxygen content in wastewater, which helps with the decomposition of organic matter and the growth of microorganisms.
2. Material conveying: suitable for conveying materials such as powder, granules, gases, etc., such as cement, grains, chemical raw materials, etc.
3. Aquaculture: providing sufficient oxygen for fish ponds, shrimp ponds and other water bodies to ensure the survival and growth of aquatic organisms.
4. Other applications: It can also be used in fields such as pneumatic conveying, vacuum packaging, and vacuum metallurgy.
5、 Brand and Price
There are multiple brands of 80 type Roots blowers on the market, such as Changsheng and Sante. In terms of price, it varies depending on factors such as brand, configuration, and material, usually ranging from a few thousand yuan to tens of thousands of yuan. Specific prices need to be consulted with relevant manufacturers or distributors.
6、 Maintenance and upkeep
In order to ensure the normal operation and extend the service life of the 80 type Roots blower, regular maintenance work is required. This includes checking the quality and quantity of lubricating oil, listening to the sound of equipment operation to determine if there is a malfunction, regularly cleaning the equipment, and checking for loose fasteners. In addition, regular major repairs and replacement of worn parts should be carried out according to the usage of the equipment and the manufacturer's recommendations.
In summary, the 80 type Roots blower is a gas conveying equipment with a wide range of applications and excellent performance. When selecting and using, appropriate selection and maintenance work should be carried out according to specific application scenarios and needs.
